Q: Some user’s fingerprint often can’t be verified, how can such problem be solved?
A: The following situations can result in a terminal not being able to verify a fingerprint:
(1) Fingerprint was rubbed down;
(2) Too many crinkles on fingerprint;
(3) Serious desquamation of fingers.
If the user’s fingerprint is not able to be verified, please delete it then enroll it again, or use a different finger forenrollment instead. Select the best fingers to enroll (less crinkles, etc.). When enrolling a user please make sure that the finger covers the biggest area it can on the sensor. Do a verification test right after enroll ment. It is recommended to enroll more than one fingerprint per user.
…………………………………………………………………………………………………………………………………………..
Q: What will cause a communication error between the software and the terminal.
A: Possible reasons:
1. Wrong COM setting, COM port chosen is not the COM port actually used.
2. Baud rate setting on computer COM port and fingerprint terminal is different.
3. The fingerprint terminal is not connected to power or to the computer.
4. Wrong terminal No. selected.
6. The data cable or converter is faulty.
7. Faulty COM port on computer.
…………………………………………………………………………………………………………………………………………..
Q: The LCD doesn’t display correctly after I switched on the unit, sometimes a black stripe displays on screen, how can I solve this?
A:
1. The main board of the terminal is faulty. Contact ciecoo and return products to be repaired.
2. Internal characteristic problem on LCD, you need contact ciecoo and return products to be repaired.
…………………………………………………………………………………………………………………………………………..
Q: How to eliminate the administrator on a terminal.
A: Make sure the terminal and the computer is connected, go into device management in the software and click on the manage label page, click cancel administrator button, then eliminate it, after connection halts, T&A menu mode occurred.
…………………………………………………………………………………………………………………………………………..
Q: Why does the terminal beep twice after I try to connect with the unit.
A: When connecting to the unit using RS232communications then the baud rate on the terminal and the software is not the same. If using RS-485 communication, it might be the two communication wires swapped around or the two wires are touching each other.
…………………………………………………………………………………………………………………………………………..
Q: When I turn on the terminal it displays “Remove finger” time after time.
A: Possible reasons:
1. The fingerprint sensor is dirty or scratched. If it is dirty you can use adhesive tape to remove it.
2. The connected wire to the fingerprint sensor is loose.
3. The chip responsible for the fingerprint sensor is faulty.
Contact ciecoo if no 2 or 3 is suspected.
…………………………………………………………………………………………………………………………………………..
Q: When I try to download the attendance record from the terminal to the software, it shows failure or mistake midway into the communication, but when I download fingerprint templates or other management setting from terminal it works fine.
A: This can be the result of the communication cable, converter or COM port on the computer being faulty. This can affect the baud rate on the communications. Set the baud rates to 9600 or 19200 then try again.
…………………………………………………………………………………………………………………………………………..
Q: Why is there no voice on my terminal?
A: The speaker or voice chip is faulty.
…………………………………………………………………………………………………………………………………………..
Q: When I power up my terminal the startup bar cycles through but does not enter into the main idle screen.
A: Please check that the fingerprint sensor wire is not loose or broken. Send it back for repair, if it is not the reason for your problem.
…………………………………………………………………………………………………………………………………………..
Q: The time on the terminal is sometimes slower than it is supposed to be.
A: The clock crystal might be faulty.
…………………………………………………………………………………………………………………………………………..
Q: Time is ”00:00” after I reboot my terminal, why?
A: The battery in the terminal may be faulty, please send back to your supplier for repairs.
…………………………………………………………………………………………………………………………………………..
Q: Why is there no beeps on pressing key sensor a voice on my terminal?
A: The buzzer, speaker or circuitry is faulty.
Scope of services for ciecoo F series time attendance access controller
Q. I can’t open the software after the installation, what should I do?
A: Check whether the Framework.net 2.0 is installed or not. Install the dotnetfx. Exe file under the Framework folder under the installation cd, and be attention for the Prompt box of the anti-virus software. The software has already been opened but minimize to the lower right corner of the desktop.
…………………………………………………………………………………………………………………………………..
Q. Why I cannot install the Framework?
A:(1) You’re not the system administrator of the windows;
(2) The installation has been estimated threatening and been stopped（you should close the anti-virus software first, restart the computer when the installation is finished）.
…………………………………………………………………………………………………………………………………..
Q. Why theDevice fails to connect with PC?
A: (1) Check if the data cable of the machine is correct;
(2) Check if the power line is working and start up the machine;
(3)Check if the communication mode and parameter are correct;
(4) If using the USB communication, check out whether the USB driver is set up or not;
(5) If none of the above reasons, please open and run the Check.exe under theRims installation directory.
…………………………………………………………………………………………………………………………………..
Q. How to install the driver for the USB communication device? (the installation is no need for serial interface, TCP/IP devices )
A:The prompt box will display Successful Connect after the connection, insert CD and click Next step.
…………………………………………………………………………………………………………………………………..
Q. The time of the machine is not correct, what should I do?
A: DeviceManagement -> Normal-> Synchronous Time Device (Synchronize device time and the current computer time.)
…………………………………………………………………………………………………………………………………..
Q. How to display the username on the screen of the machine? (Follow this method to copy fingerprint data when there’re 2 or more machines.)
A: Get theDevice connected; User Management -> choose the Device ID (Device);right-click the chosen user -> Get all enroll -> Upload enroll ->Upload Username.
…………………………………………………………………………………………………………………………………..
Q. Why there’s no data in the report?
A: (1) Check if the data has been acquired;
(2) Check if the personnel information is written;
(3) Check whether the enroll ID is in accordance with the number of the attendance machine or not;
(4) Check if the personnel’s date of entry is correct;
(5) Check whether the default shift is correct or not;
(6) Check if the machine time, report query time is correct;
(7) Check if the data statistics has been done.
…………………………………………………………………………………………………………………………………..
Q. There’re too many columns in the report, what should I do to delete some of them?
A: Right-clickmthe column of the report -> display/hidden columns -> select the wanted/unwanted ones -> save.
…………………………………………………………………………………………………………………………………..
Q. What can I set in the Attendance Rule Setting?
A: Attendance management -> Attendance Rule: Late/Early/Absence rules, Duty time, Shift,Weekend, Holiday, Overtime Rules.
…………………………………………………………………………………………………………………………………..
Q. What can I do with the data after reinstalling operating system?
A: SystemMaintenance -> Restore DB; re-input the personnel name, enroll ID (which will display in the screen of the machine when punching the card) and other information, acquire all the data again, then process the data.
…………………………………………………………………………………………………………………………………..
Q. The device cannot be entered when the administrator is changed, what should I do?
A:Device management -> Normal-> Cancel Administrative Authority; Re-enroll the administrator.
…………………………………………………………………………………………………………………………………..
Q. Is there any electronic document for help?
A:the user manual is build in the software while install, just download the software to check
…………………………………………………………………………………………………………………………………..
Q.What operations should be handed over when the administrator’s resigning?
A:Fingerprint enroll, backup enroll，administrator enroll, cancel administrative enrollment
Online Fingerprint Sensor
Q: Can dust on the sensor affect the identification performance?
A: A spot of dust will not affect the read, but a mass of dust will lead to difficulty of reading. To clean sensor use adhesive tape to remove dust.
…………………………………………………………………………………………………………………………………..
Q: There is some grime on my terminals sensor. Will it have a obvious disadvantage in using the terminal?
A: The grime is caused by sweat from fingers. Use a damp soft cloth to wipe the sensor.
…………………………………………………………………………………………………………………………………..
Q: What should I do if my sensor glass is broken or discoloured?
A: Please email us at sales@ciecoo.com then we will offer you a new glass as replacement.
…………………………………………………………………………………………………………………………………..
If you cannot find answers you are looking for, then please contact our technique support.
How to connect biometric device with our Access control?
Now, many customers get a problem that how to connect biometric device ( such as finger reader ,facial device etc) to controller and how to operate in the software.
Now let’s introduce how to connect biometric device with our access controller by example as finger reader:
This solution also suitable for how to connect facial recognition to controller.
Here’s the solution
1、Connection fingerprint card reader with Access Control
The default output of Fingerprint reader is wiegand 26 bit. so there has connection the cables with d0 , d1 ,GND for access control!
Generally that is better to use the power supply with fingerprint card reader , because of sometimes the controller will have not enough current flow to support fingerprint card reader.
2、Operation between fingerprint card reader and access controller
Only users registered on finger reader can output wiegand 26 bit , otherwise can’t..
Generally , the default wiegand output format is deviceNo. + register No. then you can register card No. in access controller software.
For example：the fingerprint device No. is 1, and the user registerNo. is 100,so the appeared No. is 100100 on the Access Control software , then you assign privilege to this user , finally the user registered on fingerprint card reader can open the door.
There is two ways to see the Wiegand output format how to appeared on access controller software:
First one: click add by reader:
Second one: click monitor
You can see the fingerprint wiegand output format on access controller software through these two ways
How to do OEM software?
You can do OEM software CD with your company own Logo ,company name , then you need make CD by yourself then sent to your customers !
Notice: Never run the files under the catalogue of copy ！！！
…………………………………………………………………………………………………………………………………………………..
Open the software CD , copy all the files to other catalogue of disk
…………………………………………………………………………………………………………………………………………………..
Step 1: Replace company Logo
The company logo photo file is named as “about logo.jpg”
Under“zh-CHS”
Pixel:145*145
The logo photo appears in the menu “help/about”
The new logo photo should be renamed exactly to “about logo.jpg”, and format should be jpg; Pixel should be 145*145. just copy the new logo photo into “zh-CHS” and replace the old one.
For example as :
After replacement, example：
…………………………………………………………………………………………………………………………………………………..
Step2: Change the background interface photo
Under zh-CHS, file named as “backImage.jpg”, pixel: 1500*700
After replacement, example:
…………………………………………………………………………………………………………………………………………………..
Step3:Change the log in interface pic
Underzh-CHS, file “loginImage.jpg”, pixel:313*209
After replacement, example:
…………………………………………………………………………………………………………………………………………………..
Step4: Change the title text of the main interface:
Open the database”ic card. mdb”which is under the folder “en” ,
Databasepassword is 168168
Open the data sheet t_a_SystemParam
…………………………………………………………………………………………………………………………………………………..
Step 5 : hange the “f_Value” which is in the row of17th
For example, input “Wiegand Access Control”.
But there can be no more than 25 characters .
…………………………………………………………………………………………………………………………………………………..
Step 6:
Save theDatabase and exit, copy the iCCard.mdb into zh-CHSStyle, and delete the default file iC Card_Default.mdb, then rename the iCCard.mdb as iC Card_Default.mdb.
When allis done, the OEM version is ok.
…………………………………………………………………………………………………………………………………………………..
Step 7: Burn Disc
Use Neroor other software for Burn Disc
Select all the files and burn them.
How to make the software use sql server 2000?
If you want your software use SQL database ,you need to install the SQL server 2000 first.The default database is access.
………………………………………………………………………………………………………………………………………………….
Step 1: Install SQL server 2000.
a. put the CD into CD-ROM.
b. Click SQL server 2000 components , then next ,
c. Keep clicking next until appearing follow interface, choose use the local system account ,then click next
d. Choose mixed mode ,you can set the SQL password ,or set empty password.
e. Then keep clicking next until installation..finished.
………………………………………………………………………………………………………………………………………………….
Step 2: run service manager
Then Click start and select
…………………………………………………………………………………………………………………………………………………..
Step 3:Set the software use SQL database
a. open the software directory , (default C:iCCard)
find sqlServerConfig.exe ,
then run it.
b. ChoseSQL server Authentication, if you have set the SQL password ,pls input it, otherwise keep empty.
c. Create new database, then confirm.
Finally open the software to check .if the here display SQL ,
this means the software is using SQL database.
SQL server database sharing
Run the program “SQLServerConfig.exe” under the software installation directory in your computer.
Then click new connection, select this one
Next,
Finally, click “ test connection” :
Now, SQL server database sharing successfully.
operation
The question is that software can be done by more than one computer.And there is a solution through shared the folder.
………………………………………………………………………………………………………………………………………..
please do as follows:
1、you needs two computer at least, one is server, another is client. they also have installed this software.
2、on the server ,please share the folders named ic card. the folders’s share permissions must be written.
3、on the client, please connect the server database throughServer_Setting.exe which in the installation directory.
4、after the success of connection.please open the software to confirm the information is as same as the server.if is the same, you can operate the software by each computer.
software can be done by more than one computer
The question is that software can be done by more than one computer.And there is a solution through shared the folder.
…………………………………………………………………………………………………………………………………………………..
please do as follows:
1、you needs two computer at least, one is server, another is client. they also have installed this software.
2、on the server ,please share the folders named ic card. the folders’s share permissions must be written.
3、on the client, please connect the server database throughServer_Setting.exe which in the installation directory.
4、after the success of connection.please open the software to confirm the information is as same as the server.if is the same, the you can operate the software by each computer.
SQL server database sharing
Run the program “SQLServerConfig.exe” under the software installation directory in your computer.
Then click new connection, select this one
Next,
Finally, click “ test connection” :
Now,SQL server database sharing successfully.
TCP IP Access Control internet setting
2015-08-14
TCP IP Access Control internet setting:
1. Connect：Please connect the Access Control to PC with net cable (by HUB orSwitch).
2. Check the LED of Controller：
light RX/LINK on, indicate working normally.
Light RX/LINK off, indicate failed connection. please check the network connection.
Notice：Please close the firewall if your computer have installed it.
If your operation system is windows xp, pls close its firewall.
◆ If all the Access Controls are spread with Small LAN ,please reference chapter 1;
◆ IfAccess Controls are spread in medium size LAN with different segments ,please reference chapter 2 ;
◆ If users want to visit the controller via Internet please reference chapter 3;
…………………………………………………………………………………………………………………………………………………..
Chapter 1 Small LAN in same segment
All controller and computer work in same segment of small LAN , operation as follows ：
1. Search Controller for test
Click Basic setting —— Controller
Click 【Search.Net】
Such interface appears if the searching controller successfully
Click 【Search】 Button，to refresh the search result;
Notice：If searching failed，means these controllers failed to connect with LAN ,please check the reason as follows :
1. Pls check whether the firewall closed ,if not, close it.
2. Pls check whether the net cable in good condition, if not, change a new one.
…………………………………………………………………………………………………………………………………………………..
2. Add Controller
Click 【Basic Setting】 — 【Controller】 —【Add】 Please reference interface as follows :
Notice：fill in the series number of controller displayed as S/N on board
…………………………………………………………………………………………………………………………………………………..
3.Check the communication between Access Controller and Software。
【BasicOperation】—【Console】— 【Check】
◆ Working normally shows as green :
◆ Failed communication shows as red:
…………………………………………………………………………………………………………………………………………………..
Chapter 2 Mediumsize LAN with different segment
Applications description
Controller and computer are spread indifferent segment. Computer in one segment and controller in another segment.
Solution as follows:
1. Search Controller in same segment. The steps pls reference chapter 1.
2. Setting Controller IP Address
In the search interface, selectedController which one want to be set IP Address (the ip address is in another segment ,not the same with computer),click 【edit】or double click. :
Fill in the new IP Address， click 【ok】.
After that , the controller IP Address withS/N：31059 change as 192.168.168.51,
But your computer is not in 168 segments.
Then put the controller in 168 segment network.
You can ping controller IP address ,if through, you can add controller to software and manage it.
…………………………………………………………………………………………………………………………………………………..
Chapter 3 Internet Setting
Users Visit Controller via the Internet, just for a dynamic domain name or a static public IP. Then you can manage controller via internet.
Essential Condition
1．Set controller ip.
2. Need a router, the router support port forward.
3. Apply for a domain name, usually the ADL distributed is a dynamic IP.
Set controller ip, pls reference chapter 1.
Open router interface. Set port forward to controller ip. the controller default port is 60000, you surely can change it .
Apply for a dynamic domain name from domain website.
After this, you can add the controller to software and manage it.
Wg3721.gicp.net is a domain name we applied for from domain website.
After steps, you can see the settings are successful.
